MAP-2
Single-Band Marine Access Point
Discontinued
Quickly and easily connect to your existing network to add or expand wireless coverage. When paired with an Aigean Networks Wi-Fi Client or Router, you can manage any connected access points directly through their interfaces.
Powerful 2.4 GHz 802.11bgn
Integrated control through Wi-Fi Client and Router interfaces
Plug and play
Easy Setup
Installation is fast and easy. No CD or software installation is required. Simply mount, plug in and power on. The interface is web-based so anything with a browser will work!
2x2 MIMO
Instead of sending one data stream, multiple data streams are sent in parallel, when possible, improving the data rate with supported devices.
Aigean Compatible
Compatible with any Aigean Networks Wi-Fi client device. When on the same network, control the MAP directly through the Wi-Fi interface in your browser.
We back our devices — and our customers — with the best limited warranty in the industry.
The MAP-2 is backed by a two-year limited warranty and includes lifetime technical support by our dedicated and knowledgeable team. Rest assured that we have you covered by the best, for the best.
Technical Specifications
| System Information | |
|---|---|
| Processor Specs | Atheros MIPS 74Kc, 550MHz |
| Memory Information | 128MB SDRAM, 8MB Flash |
| Networking Interface | 1 x 10/100 BASE-TX (Cat 5, RJ-45) Ethernet |
| Radio (2.4 GHz) | |
| Protocol(s) | 802.11b/g/n Wi-Fi with MIMO (2x2) |
| Tx Power | ≤20 dBm (100 mW) |
| Receive Sensitivity | minimum -96 dBm |
| Antennas | 2x Integrated 3 dBi Omni |
| Physical / Electrical / Environmental | |
| RF Connector | None - Internal Antennas |
| Enclosure Size | 11.9" x 9.3" x 1.5" (300mm x 266mm x 36.7mm) |
| Weight | 0.64lbs, 0.95lbs with Mounting Kits (0.29kg, 0.43kg) |
| Enclosure Characteristics | Plastic saucer-style enclosure |
| Power Method | Passive Power over Ethernet (12-24V) |
| Operating Temperature | 14°F to 158°F (-10°C to 70°C) |
| Operating Humidity | 5 to 80% Noncondensing |
| Shock and Vibration | ETSI300-019-1.4 |
| Environment Resistance | IP60 (NEMA 1) |
Disclaimer: All products, product speficiations and data are subject to change without notice to improve reliability, function, design or otherwise.
