AN-200

Long-Range, Single-Band Wi-Fi Client

The AN-200 is our mid-tier model with respect to wireless capabilities and maximum throughput. The device is contained in a beautifully rugged case, with regulated power supply, and a larger, higher-efficiency marine antenna over that included with the LINK series.

As with the entire AN-2x series, the AN-200 is at home on both the hardest working sportfish boat and high end motor yachts. Performance and years of service are ensured with the use of high quality components and inclusion of industry trusted Comrod antennas. The AN-200 includes a superior power regulation system that allows efficient operation from 8 to 35 V DC. Additionally, a unique mounting system makes it easy to attach to any surface.


Device Features
High-Gain Antenna
The high-powered radio is complemented perfectly by a high-gain, marine-grade Comrod antenna to ensure the best signal possible.*
Advanced Power Supply
Includes a high-efficieny step up/down power supply that regulates 8VDC to 35VDC to clean, adjusted internal power.
Long Range
Connect to networks up to 7 miles away in ideal atmospheric, line-of-sight, and optimum hardware conditions.

Aigean Wi-Fi Clients are used as the primary connection interface for communicating with external wireless networks. Our wireless clients are designed to improve signal strength and quality when connecting to marina, hotel, home, and business networks.

Installation Notice: This device is intended to be professionally installed. Installation requires proper antenna placement and mounting, cable run(s) and termination, and 12V DC power connection. Failure to meet installation guidelines and requirements may void device warranty.

Package Contents

  • AN-200 device
  • Comrod marine antenna (4ft /121 cm)
  • Secondary rubber antenna (5in / 12 cm)
  • LMR-400 low loss cable (25ft / 762 cm)
  • LMR-400 N-Male connector w/ heat shrink
  • Power cable (6ft / 182 cm)
  • Quick Start Guide
  • Warranty Information

Compatibility

Modern Web Browsers

Chrome, Safari, Firefox, Opera, Microsoft Internet Explorer 10 and newer, Microsoft Edge

Standard 802.11b/g/n Wi-Fi networks

  • Unsecured (Open)
  • Standard Encryption (WEP, WPA, WPA2)
  • Hidden Networks (masked SSID)

We back our devices — and our customers — with the best limited warranty in the industry.

The AN-200 is backed by a two-year limited warranty and includes lifetime technical support by our dedicated and knowledgeable team. Rest assured that we have you covered by the best, for the best.

Warranty Information


Optional Upgrade Kits

Improve wireless performance by upgrading standard antennas on LINK models, or the secondary MIMO antennas for premium devices. Kits must be properly paired by matching model and wireless band.



Advanced Antenna Kit

Replace secondary MIMO antenna below deck for improved performance.
Compatibility AN-2000, AN-7000
Band 2.4 or 5GHz
Antenna 1x 16" Marine
Includes Mounting bracket

Premium Antenna Kit

Add a secondary MIMO antenna above deck or a LINK antenna for optimum performance.
Compatibility LINK2/5, AN-2000, AN-7000
Band 2.4 or 5GHz
Antenna 4' Comrod
Includes 1" - 14 thread mount
25' LMR-400 low-loss cable


Technical Specifications

System Information
Processor Specs Atheros MIPS 74Kc, 550MHz
Memory Information 128MB SDRAM, 8MB Flash
Networking Interface 1 x 10/100 BASE-TX (Cat 5, RJ-45) Ethernet
Radio (2.4 GHz)
Protocol(s) 802.11b/g/n Wi-Fi with MIMO (2x2)
Tx Power ≤28 dBm (800 mW)
Rx Sensitivity minimum -96 dBm
Physical / Electrical / Environmental
RF Connector 2x N-type Male Jack
Enclosure Size 11.9" x 9.3" x 1.5" (300mm x 266mm x 36.7mm)
Weight 5 lbs (2.27 kg)
Enclosure Characteristics Powder coated die cast aluminum enclosure
with rubber seal, ABS plastic mounting plate, and stainless steel hardware
Power Rating 8-35 V DC - input internally regulated
Operating Temperature -22°F to +167°F (-30°C to +75°C)
Operating Humidity 5 to 95% Condensing
Shock and Vibration ETSI300-019-1.4
Environment Resistance IP65 (NEMA 4)
Disclaimer: All products, product speficiations and data are subject to change without notice to improve reliability, function, design or otherwise.
Performance Notice: Actual performance may vary. The standard transmission rates described are the physical data rates. Actual data throughput will be lower and may depend on the mix of wireless products used and external factors. Factors affecting signal strength and quality include local radio interference, obstacles impeding clear line-of-sight, antenna positioning, access point hardware/configuration, and atmospheric conditions, among many others.
Regulatory Compliance: Specified transmit power is the maximum output power the radio hardware is capable of. The device's firmware controls power limits based on established country-wide regulations to ensure safe and legal operation. All devices are defaulted by the factory to operate in the United States of America, following all applicable FCC rules & regulations.
