AN-700
Long Range, Dual-Band Wi-Fi Client
The AN-700 is a lighter take on the AN-7000, Aigean's most popular and capable Wi-Fi client featuring high powered dual-band connectivity. The AN-700 features the same dual-band connectivity with a single antenna and half of the power, in comparison.
From the attractive, powder coated case to the elegant and intuitive firmware, the AN-700is perfect for vessels of all types and sizes.
Top-tier performance and years of service are guaranteed with the use of the highest quality components and inclusion of industry trusted Comrod antennas. The AN-700 includes a superior power regulation system that allows efficient operation from 8 to 30V DC. Additionally, a unique mounting system makes it easy to attach to any surface.
Aigean Wi-Fi Clients are used as the primary connection interface for communicating with external wireless networks. Our wireless clients are designed to improve signal strength and quality when connecting to marina, hotel, home, and business networks.
Package Contents
- AN-700 device
- Comrod marine antenna (4 ft / 121 cm)
- LMR-400 low loss cable (25 ft / 762 cm)
- LMR-400 N-Male connector w/ heat shrink
- Power cable (6 ft / 182 cm)
- Quick Start Guide
- Warranty Information
Compatibility
Modern Web Browsers
Chrome, Safari, Firefox, Opera, Microsoft Internet Explorer 10 and newer, Microsoft Edge
Wi-Fi Networks
All standard 802.11a/b/g/n Wi-Fi networks:
- Unsecured (Open)
- Standard Encryption (WEP, WPA, WPA2)
- Hidden Networks (masked SSID)
We back our devices — and our customers — with the best limited warranty in the industry.
The AN-700 is backed by a two-year limited warranty and includes lifetime technical support by our dedicated and knowledgeable team. Rest assured that we have you covered by the best, for the best.
Technical Specifications
| System Information | |
|---|---|
| Processor | Atheros MIPS 74Kc, 600MHz |
| Memory | 64MB SDRAM, 64MB NAND Flash |
| Networking Interface | 1 x 10/100 BASE-TX (Cat 5, RJ-45) Fast Ethernet |
| Radio (2.4 GHz / 5 GHz) | |
| Protocol(s) | 802.11a/b/g/n Wi-Fi |
| Tx Power | ≤27 dBm (500 mW) |
| Rx Sensitivity | minimum -97 dBm |
| Physical / Electrical / Environmental | |
| RF Connector | 1x N-type Male Jack |
| Enclosure Size | 11.9" x 9.3" x 1.5" (300mm x 266mm x 36.7mm) |
| Weight | 5 lbs (2.27 kg) |
| Enclosure Characteristics | Powder coated die cast aluminum enclosure with rubber seal, ABS plastic mounting plate, and stainless steel hardware |
| Power Rating | 8-30 V DC - input internally regulated |
| Operating Temperature | -40°F to 158°F (-40°C to +70°C) |
| Operating Humidity | 5 to 95% Condensing |
| Shock and Vibration | ETSI300-019-1.4 |
| Environmental Resistance | IP65 (NEMA 4) |
